Energy-saving lamps

Replacing incandescent bulbs with modern energy-saving bulbs can, on average, cut your home's electricity consumption in half. The energy-saving lamp lasts 10 thousand hours. while an incandescent lamp takes an average of 1.5 thousand hours, that is, 6 - 7 times less.
An 11 W compact fluorescent lamp replaces a 60 W incandescent lamp. The costs are recouped in less than a year, and it lasts three to four years. Calculated: replacing in an apartment with an area of ​​45 - 50 sq. meters of lamps with conventional lamps for fluorescent, you can save about 1500 kWh per year. It is more advisable to use compact fluorescent lamps in the corridor and in the kitchen, where the light burns longer. If you are not used to turning off the lights after you, then this is the most acceptable way to save both electricity and money.

Savings: up to 1000 rubles.

Use voltage stabilizers. Power engineers advise using voltage stabilizers! By connecting a computer or TV through the stabilizer, you can achieve a significant reduction in power consumption.
The "sleeping" state is deceptive
Anyone who thinks that household electrical appliances that are not working, but connected to the mains do not consume electricity and do not affect the amount of electricity bills, they are mistaken. Electricity is consumed in such a "sleeping" or standby state when only the "red eye" on the panel of the household electrical appliance is turned on. So how much electricity is consumed by non-working TVs, video and stereos that are connected to the network, microwaves?
Studies have proven that the consumption of electricity for devices in a standby state is about 10% of the total electricity consumption! So, on average, the TV works about 4 hours a day. The rest of the time "at idle", being simply connected to the network, it consumes about 1.1 kW / h of electricity per day, per month - 33 kW / h. Microwave

The oven, the video recorder "eat" 0.4 kW / h per day, 12 kW / h - per month. And one hour of idle operation of the electric heater will ruin 1.4 kW / h per day or 42 kW / h per month.

Savings: up to 300 rubles.

How much does the refrigerator "eat"?

The refrigerator is one of the most energy-consuming appliances. It is constantly connected to the network and consumes as much electricity as an electric stove. A tidy figure comes up per year: compressor refrigerator - 350 - 550 kW / h, absorption refrigerator - 600 - 1600 kW / h.
The economy of the refrigerator, first of all, depends on the mode of its operation, associated with the frequency of use, and compliance with the rules of operation. At correct operation refrigerator energy consumption is reduced by 15 - 20%.
After opening the refrigerator door three times, the electricity consumption increases by 1%!

Savings: up to 300 rubles.

If you want to be richer - know how to save
Do not use the hob without a “good reason”. After all, everyone knows: to drink tea, for example, it is better to use a less energy-consuming device - an electric kettle. Thus, you can save up to 250 kWh per year.
Monitor the health of the stove. Using faulty burners leads to an overconsumption of electricity by 3 - 5%.
What kind of utensils you use plays a big role. You can save energy by using special cookware with a thicker bottom equal to or slightly larger than the diameter of the burner. Energy saving when using such cookware is from 140 to 280 kWh per year.
Using crockery with a curved bottom can result in an overconsumption of electricity up to 400 kWh per year.
By the way, an important fact. If you cook food in a bowl without a lid, you will consume three times more energy!
Electrical appliances consume 48% of the electricity consumed, lighting 12%, and cooking 40%. The annual electricity consumption of a family with an electric stove is 3500 - 4000 kW / h.

Savings: up to 400 rubles.

Which irons are economical? Use the temperature regulator to iron a particular type of fabric. Why heat your iron to its maximum temperature and then wait for the iron to cool down to iron the synthetic fabric? You are wasting both time and energy.
Buy irons with stepless steam control, depending on the type of fabric. If you need to steam hard-to-iron fabric, for example, jeans, you can use the enhanced steam mode. The "LOW PRESS" mode allows you to steam delicate synthetic fabrics by supplying steam when working at low temperatures.
If you still use an iron without a temperature regulator, it's time to think about purchasing a more modern one, in which the heating time is reduced from 15 - 20 minutes to 6 - 7 minutes, energy consumption is reduced by more than 20%.

Savings: up to 500 rubles.

Load the vending machine completely
From the point of view of electricity consumption, the most economical automatic washing machines... The main rule of thumb for economy is full load. Do not start washing until you have accumulated enough laundry to fully load the machine!
Try to wash at a lower temperature. At a washing temperature of +90 "C, electricity consumption is 30 - 40% higher than at a washing temperature of +60" C.
Use energy saving programs: by lengthening the wash duration, you can lower the water temperature. In this case, the energy savings will be 45%, because the main electricity consumption goes to heating water.
By hand washing particularly dirty stains and soaking dirty laundry, you can avoid the need for washing at high temperatures and high energy consumption.

Savings: up to 900 rubles.

Insulate your apartments well
Heat energy losses heating system in residential buildings account for almost 20%! Most of the heat loss occurs:
- due to non-insulated windows and doors - 63%;
- through window panes - 15%;
- through ceilings and walls -15%.
Many, instead of home insulation, use electric heating devices in addition to the heating system, which leads to increased electricity consumption. Northerners, like no one know: insulation is the best energy saving.

Savings: up to 600 rubles.

Saving energy when consuming water
Did you know that up to 2,000 liters of water per year flow out of the faucet from which water drips (10 drops per minute).
And if each of the four members of your family leaves the water tap open for only 5 minutes a day, you lose 7 kWh of energy, throwing 1000 rubles out the window?
Taking a shower is much cheaper than taking a bath. Taking a bath (140-180 l), you expend three times more energy than taking 5 minutes. shower.
Sprayers on taps allow for more efficient use of water.

Savings: up to 1000 rubles.

And:
- insulate windows and doors to prevent heat loss!
- do not obstruct the heating radiators with furniture and curtains!
- turn off the light when you leave the room!
- install counters cold and hot water!
- use a table lamp when there is no need for general lighting rooms!
- when cooking on the electric stove, turn it off a few minutes before the food is ready!
- Cover the pan with a lid when cooking!
- install two-tariff electricity meters!

Following the tips on energy saving, you can put in the family budget from 3000 to 5000 rubles a year, which is 25% of the family's energy consumption expenses.

Today every family knows - savings are important, savings are needed!

Automated commercial and technological metering of consumption of cold and hot water, gas, electricity, heat energy.

Composition of ASKUE "Pulsar"

1. Energy meters entered in the State Register of Measuring Instruments of the Russian Federation, equipped with a pulse telemetry output or a digital output (, meters of active and reactive electricity, including transformer switching, gas measuring complexes)

2. Pulse counters - recorders "Pulsar" (State Register No. 25951-03) - secondary devices, each of which is connected to up to sixteen primary meters with a pulse output. used for:
- accumulation of pulse information from primary counters with its binding to astronomical time
- maintenance of one-rate or two-rate electricity metering using one-rate electricity meters
- data transmission in digital format to the dispatcher's computer (RS485 standard)

3. Data collection and transmission devices (DRC) providing data collection from Pulsar recorders, from energy meters with digital output, storage and transmission of data to the upper level of the system, synchronization of metering devices. installed directly at the facility. The use of DRC is not a prerequisite system operation

4. Assistive devices, providing the transmission of digital information (, repeaters,)

5. Custody transfer server, workstations

List of devices with digital output supported by ASKUE "Pulsar"

Functions of ASKUE "Pulsar"

- maintaining a database of resource consumption on a PC;
- preparation of analytical information, reports, protocols, graphs for subsequent printing;
- billing subscribers to pay for consumed energy resources;
- informing consumers about the state of payment and resource consumption;
- reduction of the intra-facility balance of incoming and outgoing energy resources in order to identify hotbeds of unauthorized consumption;
- data delivery and exchange of analytical information between housing and communal services structures and energy supplying organizations;
- correction of the internal clock of pulse counters-recorders and energy meters with digital output.
- multi-tariff metering of energy resources
- control of communication lines with energy meters
- protection of information from unauthorized access

Advantages of ASKUE "Pulsar"

Affordable cost of equipment and installation

A minimum of functional blocks and a minimum length of wires are used, which is achieved by using a parallel principle of connecting pulse counters - recorders to a common line.

Reliability

All information about resource consumption before entering it into the PC is stored in the non-volatile memory of pulse counters - recorders. In the event of a mains power failure, data logging continues. The absence of intermediate blocks for storing information between the pulse counter - recorder and the computer minimizes the likelihood of data corruption and system failures. The use of hardware for data transmission via the RS 485 protocol excludes the influence of pickups, interference, etc. during data transmission.

Convenience and ease of maintenance

People who set up and maintain the system do not have to undergo long-term training, have appropriate education, etc. The interface of the software part, as well as the entire structure of the system, is intuitive and simple. Using the 485/232 adapter allows you to read information in a PC (including a portable one) right on the spot. In the case of an available free telephone line, it is convenient to transfer information to a remote computer via a regular telephone modem. If there is no telephone line, it is convenient to transfer information via a GSM modem. Operational control over the operation of the main functional cell of the system - impulse counter - recorder, is possible on site according to the readings of the built-in LCD. Almost unlimited possibilities in terms of the length of the communication line and the number of counters - registrars in the network make the system universal for use on different types objects.

Variety of functions

The variety of functions meets all modern requirements for such systems. There is a possibility of increasing functions without changing overall structure systems.

Openness, compatibility, security

The system is built on the basis of open data transfer protocols, but the data is protected from unauthorized reading. The system has its own OPC server. When working with data, the consumer of information can use both the software supplied with the system and his own software. The software is compatible with calculation programs.

Thanks to these advantages, ASKUE Pulsar is unique in its kind.

Industry solutions

1. Automated housekeeping of energy resources (water, gas, heat, electricity)

2. Automated accounting in odes

- automated metering of water in apartments
- automated metering of water in the hotel
- automated water metering in a shopping center
- automated water metering in the private sector (cottage community)
- a automated accounting and dispatching system at water utility facilities

energy accounting in buildings and structures

based on technologies of wireless sensor networks and smart sensors

Intelligent energy-saving system for accounting of energy resources in buildings and structures based on technologies of wireless sensor networks and intelligent sensors (hereinafter - IES) intended for automated metering of energy resources, regulation of energy consumption and dispatching of energy resources (heat metering, heat metering, water metering, electricity metering), as well as the transmission of alarm notifications in the interests of reducing the costs of end users, heat supply and operating organizations, housing and communal services, ensuring comfortable living conditions and prevention of accidents and emergencies.

Intelligent energy saving accounting systemenergy resources performs the functions:

• individual (apartment-by-door) multi-tariff metering of hot and cold water and accounting electrical energy;
• individual (door-to-door) receipt and accumulation of initial data (temperatures of heating radiators and temperatures in living quarters) for calculating the consumed thermal energy using a proportional scheme based on data from a general house heat energy meter;
• processing, accumulation and storage in non-volatile memory and delivery via Internet communication channels on demand and in a planned mode of data on energy consumption to the regional (city) server for energy consumption accounting and dispatching;
• monitoring and visualization of data on consumed energy resources using the WEB-interface in a form convenient for the end user;
• prevention emergency situations based on the detection of water leaks and the detection of facts of abnormal (non-standard) consumption of energy resources;
• dispatching the consumption of hot and cold water in the prevention of emergencies and by commands from the regional server for metering and dispatching energy consumption;
• dispatching electricity consumption when preventing emergencies and by commands from the regional server for metering and dispatching energy consumption;
• automatic temperature control in heated rooms using daily and weekly settings of the desired temperature;
• interaction with standard sensors of the security and fire alarm system, implementation of the modes of remote arming and disarming of an apartment from protection, "Panic button", notifications of fire, gas leakage, water leakage with the transmission of alarm events to the general facility concentrator and selected subscribers of GSM networks;
• protection of the system from unauthorized access and unskilled use;
• remote setup and configuration of devices as part of the system using standardized protocols;
• maintaining archives on the regional server for accounting and dispatching energy consumption and issuing them to remote client workstations of the authorities state power and management, energy supply organizations, management companies, homeowners associations, etc.

Composition and characteristicsaccounting systemenergy resources:
1. Apartment block, structurally installed, for example, in the power panel or in any other convenient place that provides access to a 220 V network and to a computer wired Ethernet network:

• communication interfaces - TCP / IP Ethernet, RS-485, MiWi, GSM (if there is a router);
• number of supported wireless modules via MiWi interface - up to 45;
• radio communication range - up to 30 ... 100 m (depends on the specific conditions of use, in particular on the type of walls of the premises - brick, concrete, etc.);
• accumulation of information (up to several hours, depending on the number of connected accounting modules) in the absence of communication with the server and subsequent sending of the accumulated information after the restoration of communication;
• support for two servers (main and backup) with automatic transition from one to another when the connection is lost;
• redundancy of communication channels with the server - main channel: LAN Ethernet (twisted pair, RJ-45 connector), backup: GPRS GSM (if there is a GSM router);
• maintaining the functionality of the temperature control and dispatching functions in the absence of communication with the server.

Note: the apartment block is used in an individual use case and as a means of accumulating and transmitting data of metering modules for the total consumption of energy resources.
2. Water supply accounting and dispatching module:

• cold and hot water meters with pulse output with installation diameters 1/2, 3/4;
• electric cranes with installation diameters 1/2, 3/4;
• wireless digital thermometer with a temperature measurement accuracy of 0.1 ° С;
• converter "counting output-radio interface" BSI-01;
• wireless sensor of water leakage BDUV-01;
• valve control module with radio access MUV-01.

3. The module for accounting and regulation of heat supply, consisting of:

• electrically controlled (or manual thermostatic) valve;
• radiator and room digital thermometers with radio interface.

4. Power supply accounting and dispatching module:

• an electric meter with a counting output;
• relay-limiter of consumed electric power;
• an interfacing unit with a limiter relay (load control module with radio access MUN-01);
• converter "counting output-radio interface" BSI-01.

5. The module for accounting of the general consumption of energy resources:

• apartment block in the variant of accounting for the general consumption of energy resources;
• standard object (general house) energy metering devices with RS-485, ETHERNET interfaces.

6. RRS-01 radio network repeater (for large rooms with complex layouts and private buildings).
7. Wireless IR motion sensor ODP-01.
8. Wireless fire detector PDB-01.
9. Regional (city) server for collecting and processing data on energy consumption of buildings and structures with network access, static network address and system uninterruptible power supply
10. Server software (software):

• Operating system - Windows or Linux (Unix);
• The capacity of the address space for connecting apartment blocks (individual consumers) is 65535 pcs. (up to 200 ... 300 apartment buildings), the actual number of devices depends on the performance of the computer, the transmission speed of communication lines, the intensity of data exchange;
• Continuous archiving of data received from objects;
• Increased resiliency and minimum requirements to hardware.

11. Client software:

• Operating system - Windows or Linux (Unix)
• Display of current (on-line) data both in text (tabular) and graphical (in the form of graphs).
• Viewing archives for a user-specified time interval in text and tabular form.
• Possibility of selective blocking (disconnection) of consumers.
• Remote configuration of object equipment (client software for a system engineer).

Structural scheme intelligent energy savingaccounting systemenergy resources is shown in Fig. 1.

Rice. 1 - Block diagram of an intelligent energy-saving energy accounting system

Operating procedureintelligent energy savingaccounting systemenergy resources.
Data from the pulse outputs of cold and hot water meters are fed to the input of the BSI-01 counter-output-radio interface converter, which counts the number of pulses and transmits this data via the Mi-Wi wireless network to the apartment block, which calculates the current value of the flow rate of cold and hot water with saving the result in non-volatile memory. Then the apartment block broadcasts them via Enternet to the district energy supply metering and dispatching server. Converter "counting output-radio interface" BSI-01 is battery powered.

Apartment block with top cover removed and apartment control panel (right)

At the same time, taking into account the water consumption, the temperature of the hot water pipeline is continuously monitored using a wireless temperature sensor installed on it. Temperature measurement is carried out after a specified time (20 ... 30 seconds) after the start of the current flow cycle and, when the temperature exceeds the standard parameters, information about this fact is transmitted to the apartment block with data relaying to the regional energy consumption server. This is necessary for the implementation of the legal rights of users to reduce costs in case of abnormal power supply.
When the wireless sensor of water leakage BDUV-01 is triggered, information about this is transmitted to the apartment block. Based on the given algorithm, the apartment block makes a decision on the dispatch (cut off the supply) of cold and hot water, which is indicated by a corresponding indication on the apartment panel. The command to shut off the water is sent wirelessly to the valve control module MUV-01 and is relayed by it to the executive device - a ball valve. After executing the command, a confirmation receipt for the apartment block is issued. In addition to what has been described, forced shutdown of cold and hot water from the regional server for accounting for dispatching of energy resources in the absence of payment, the need for strict limitation of consumption, etc., as well as dispatching of water by user commands, can be used.
The procedure for metering and dispatching electricity is similar to the procedure for metering and dispatching water supply.
Accounting and regulation of heat supply is carried out as follows. Data on the temperature of the heating radiator and the temperature in the heated room are transmitted to the apartment block at a predetermined frequency (100 ... 300 seconds). When a manual thermostatic valve is used, the specified data are accumulated in the non-volatile memory and, after averaging with a cycle of 3 ... 5 minutes, are sent to the regional energy consumption server. When using automatic electronic temperature control using special software of the apartment block, a loop for automatic maintenance of a given temperature is implemented based on a modified proportional control with the generation of electric valve control commands. As the initial data for regulation, daily and weekly regulation programs (profiles) are used, set by the user through the apartment panel or the WEB-interface via the network. Simultaneously, taking into account the data on the room temperature and the temperature of the heating radiators, the state of the batteries of all battery-powered wireless devices is monitored. The calculation of the consumed heat energy by each individual consumer is carried out using special software of the regional energy consumption server based on the proportional principle according to the data on the recorded temperatures, heat transfer from installed radiators and data on the promised house consumption.

A heating radiator with a temperature measurement module installed on it (right).

On the regional server for metering and dispatching energy consumption, data received via the Internet from apartment blocks are archived for later use. The server is turned on around the clock, has the necessary data backup facilities and is located in a specially designated room. Remote client workstations are connected to the server with special software for employees of government bodies, energy supply organizations, management companies, homeowners' associations and billing systems. The client software has a user-friendly user-friendly interface that allows you to observe (graphics, tables), statistically process and analyze energy consumption information.
The client software makes it possible to block consumers. In this case, after the operator has given the blocking command, it is sent from the client workstation to the energy consumption server, then to the apartment block. From the apartment block, the command is retransmitted to the corresponding module, which includes the dispatching actuator.

Connection and configurationintelligent energy savingaccounting systemenergy resources.
The power supply of the valve control module MUV-01 is carried out from power supplies (hereinafter referred to as the power supply) with a nominal voltage of 12 V. Voltage deviations should be in the range from minus 15% to plus 10% of the nominal value. The power supply for the device must be rated for a maximum current of 1 A.

Rice. 2 - MUN-01 connection diagram

Ball valves are connected to the MUN-01 board to the relay outputs.

The connection of the meter pulse output (water, electricity, etc.) to the BSI-01 board is carried out to the terminals of the counting input, while one output of the meter's pulse output is connected to the general output of the board ("minus" of the power supply), and the other to the terminal channel inlet (see Fig. 3).

Rice. 3 - Connection diagram of the BSI-01 device

The BSI-01 and MUN-01 boards are powered from a + 3V lithium battery power supply, however, it is also possible to connect an external source with a + 3 ... 5V voltage.

The power supply of the apartment block, which includes the network hub card (Fig. 4), is carried out from power supplies with a nominal voltage of 12 V. The voltage deviation should be within the range from minus 15% to plus 10% of the nominal value. The power supply for the device must be rated for a maximum current of up to 1 A.

Rice. 4 - Wireless network module of the apartment block

Setting the parameters of an intelligent energy-saving energy accounting system can be carried out both from the server and through access using the "Telnet" terminal.
Algorithm for commissioning a new device (wireless module):

• The operator sends a command to the selected apartment block to search for a new wireless device. After that, the wireless network goes into the standby mode for connecting the device with the factory address (by default, which is equal to 255).
• The operator presses and holds for 3 ... 5 seconds a special button on the device (wireless module) added to the network, after which the device establishes communication with the network node (apartment block). In this case, if the device is within the range of several wireless networks (neighboring apartment blocks) at the same time, then it will only connect to the network that was previously switched to the standby state (see paragraph 1).
• The connected device sends its factory settings (type of module, type of sensors, values ​​of scale factors for converting the readings of the sensor (meter) into the value of a specific physical quantity, etc.) to the apartment block, which then transmits the received settings to the server, which in turn - into a special utility-client program for system administration. After that, the operator is shown a form (Fig. 2.) for configuring the device with the fields already filled in, based on the received factory settings.
• The operator, if necessary, corrects some fields (device address, its name, etc.) in the specified form of settings and presses the "Apply" button. The entered settings are sent to the server, then through the apartment block (local repeater) to the added device, where it is stored in non-volatile memory.
• After the performed actions, the device turns out to be connected to the wireless network and for confirmation sends back to the Server the newly received new settings.

Before the first connection of the local repeater (RL-01) to the LAN-Ethernet network, it is necessary that the system administrator serving this network assigns an IP address and a subnet mask for the connected device, as for a network device (see Table 1 for factory settings) ), and also provided access to the data collection server TCP port 2021.

Table 1 - Factory settings of network parameters

To gain access to the WEB-interface, you must enter the device's IP address in the address bar of the browser (by default, 192.168.10.180).
The welcome page of the WEB-interface will be displayed on the screen. (fig. 5).

Rice. 5 - Start page of the WEB-interface of the intelligent energy-saving energy accounting system

Access to the start page does not require entering a password.
On the left side there is the main menu of the WEB-interface of the intelligent energy-saving energy accounting system:

• home
• Devices
• Configuration
• Daily profiles
• Weekly profiles
• TCP / IP network
• GSM network
• Magazine
• Technical support

To enter each of these pages (except for "Technical support"), you need to enter your username / password (by default Admin / start) in the authorization form (Fig. 6).

On the page of the WEB-interface "Devices", the user can view the list of all devices connected to the apartment block, as well as the values ​​of the current readings for the selected metering module (Fig. 7).
The status of the device in the radio network (connected / disconnected) and the time of its last activity are also displayed. This allows you to quickly and visually assess the operation of the system (the quality of communication with devices, the rate of data exchange, etc.).
For each of the values ​​coming from the devices, the measurement time is displayed, which allows you to have a clear idea of ​​the relevance of the data at any time.
When developing the WEB-interface, the technology was used AJAX, Ajax (from the English. AsynchronousJavascriptandXML- "Asynchronous JavaScript and XML") - an approach to building interactive user interfaces of web applications, which consists in the "background" exchange of data between the browser and the web server. As a result, when data is refreshed, the web page does not completely reload, and web applications become faster and more convenient. This allows the user to observe the changes in parameters in real time without having to press the "Refresh" button of the browser all the time.

Rice. 7 - Page of the WEB-interface of the energy accounting system - "Devices"

On the page of the WEB-interface of the "Configuration" energy accounting system, complete information about the composition of the BSS, the parameters of the devices included in it, etc. is displayed. (fig. 8).

Rice. 8 - Page of the WEB-interface of the energy accounting system - "Configuration"

On the page "Daily profiles" of the energy accounting system (Fig. 9), the user can set up to 4 different (according to the TOR) daily temperature control profiles. Each such profile contains 4 time intervals, during which a certain temperature value is maintained. Thus, it is possible, for example, to generate weekend profiles for the energy accounting system (when all the time, except for the night, heat) and a weekday (working) day (when all residents are outside the apartment - the temperature can be reduced), thereby saving energy resources.

Rice. 9 - Page of the WEB-interface of the energy accounting system - "Daily profiles"

The user has the ability to set up to two weekly temperature profiles, each of which determines which of the 4 daily profiles to regulate the temperature on each of the 7 days of the week. You can edit weekly profiles on the “Weekly profiles” page of the WEB-interface (Fig. 10).
On the following pages of the WEB-interface ("TCP / IP network", "GSM network", "Log" and "Technical support"), the user or the system administrator can change the network settings and view the protocol (log) of events.

Rice. 10 - Page of the WEB-interface of the energy accounting system - "Weekly profiles"

The apartment block of the energy metering system also has the ability to connect via Telnet. This is necessary, first of all, for engineers involved in commissioning and maintenance of PWIs. In the Telnet access mode, you can get much more detailed information about the state of the system, in comparison with the WEB-interface. (fig. 11).

Rice. 11 - Viewing the status of the energy metering system using Telnet

Using Telnet access, you can monitor the following parameters of the energy metering system in real time:
- list of devices, their type;
- availability of communication over a wireless network for each of the devices;
- the status of the last data sent to the device ("ready", "busy", "error", etc.);
- incoming and outgoing traffic (data volume) for each of the devices;
- time of the last radio communication session with the device;
- time of receipt of the latest data on the measured value;
- onboard time of the apartment block;
- the number of transmission errors / checksum errors (CRC) that occurred during data transmission from the moment the apartment block was turned on;
- total number of devices registered in the wireless network / number of devices in communication;
- the state of the connection to the server;
- the state of the queue for sending messages to devices;
- supply voltage of the apartment block;
- the operating time of the apartment block from the moment of switching on.

Rice. 12 - Window for configuring the device of the energy resources metering system via Telnet

When using Telnet, all commands are entered in text form, while their list and the required syntax (notation form) are shown in Table 3.

Table 3 - Telnet commands for configuring the apartment block.

* - possible values ​​of the "module type" parameter:
0 - Unknown device;
1 - Local repeater ETERNET / GSM (RL-01);
2 - Housing and communal services load control module with radio access (MUN-01);
3 - Wireless heat distributor (BRT-01);
4 - Wireless pulse counter (BSI-01);
5 - Radio network repeater (RRS-01);
6 - Apartment display and control panel (KPIU-01);
7 - Receiving and transmitting device (PPU-01);
8 - Wireless security infrared motion sensor (ODP-01);
9 - Wireless fire detector (PDB-01);
10 - Wireless water leakage sensor (BDUV-01);
11 - Security module;
12 - Wireless temperature sensor (BDT-01).

Brief description of the client and server software for the energy accounting system.

The external view of the server software of the energy accounting system is shown in Fig. 13.

Rice. 13 - Server software (software) of the energy resources accounting system

Energy metering system client software includes 2 client applications:

• • Client software for the energy metering system for configuring the system and viewing instrument readings in the On-Line mode (client for the engineer and system operator);
  • Client software for the energy accounting system for metering the energy consumption of housing and communal services facilities, designed to determine and visualize the consumption of energy resources by subscribers for a given period of time (client software for homeowners associations and management companies).

The external view of the client software for the energy accounting system is shown in Fig. 14. On the "Object state" tab, the data received in real time from the object equipment are displayed. The left pane displays a list of devices connected to the server. The “Object status” tab displays the data received from the device, the presence of an alarm, as well as the status of the device's connection to the server and the relevance of the received data.

Rice. 14 - Client software of the energy resources accounting system, "Object state" tab

The "On-line viewing" tab displays the data received from the devices in a graphical form (Fig. 15).

Rice. 15 - Client software of the energy resources accounting system, the "On-line viewing" tab

Client software of the energy accounting system for accounting of energy consumption of housing and communal services facilities:

• • ensures the maintenance of a database containing information about subscribers (legal and individuals), energy metering devices and tariffs for payment of energy consumption services;
  • provides import of energy consumption data from several servers of the energy consumption accounting system;
  • allows you to view the details of electricity consumption for an individual subscriber (or for a group of subscribers / objects) for a specified time interval (Fig. 16).
  • allows you to view the distribution of energy consumption between subscribers or objects of housing and communal services for a given time interval (Fig. 17).
  • supports the formation of receipts for payment of utility services (Fig. 18), determination of the balance of subscribers, the formation of lists of debtors.
  • supports the formation of reports on the consumption of energy resources by subscribers for a given period of time (Fig. 19).

Rice. 16 - Viewing the total consumption of cold water by an object with detailing 1 day

Rice. 17 - Viewing the distribution of electricity consumption between subscribers

Rice. 18 - An example of a payment receipt generated by the client application of the energy accounting system

Rice. 19 - An example of a report on electricity consumption by subscribers of an energy accounting system

Rice. 19 - Intelligent energy-saving energy accounting system based on wireless sensor networks and smart sensors in a shopping center building.

Any modern industrial enterprise consumes a significant amount of energy resources in various forms. Including to ensure their life and technological processes enterprises of various industries consume electricity and pipe energy resources (heating, hot water supply, etc.). The cost of purchasing energy resources is a significant share of the cost finished products, which determines the relevance of energy saving. In turn, energy saving is impossible without accurate accounting. Therefore, the first step to reduce costs will be the introduction of an integrated energy accounting system.

What is integrated energy accounting?

Comprehensive accounting of energy resources provides for the construction of a single automated system, which collects readings from all primary metering devices that measure the consumption of electricity and other resources. Information from metering devices goes to the data collection device and is transmitted to the server, where they are then processed. As a result, the company receives a detailed picture of energy consumption and a significant amount of analytical information required to optimize consumption.

Benefits of integrated energy metering

The introduction of an integrated energy accounting system has a number of advantages over the use of separate systems for each specific type of resource. First of all, it is a more economical solution due to the use of a single infrastructure for collecting data from metering devices of different resources.

In addition, the integrated system provides the following operational benefits:

• High information content. The system of integrated accounting of energy resources provides the ability to obtain data on consumption at any of the entities or structural units enterprises. It also provides the ability to control the readings of energy meters of various kinds(electricity, gas, heating, water, etc.).
• Relevance. Complex system allows you to control energy consumption in real time. It also provides the accumulation of information over the past periods for subsequent study and analysis.
• Full automation of the information collection process, which has great importance for enterprises with a complex structure and a large number of energy consumption meters.
• High level of accuracy of the received information on consumption.

Thanks to these advantages, complex energy metering is more convenient to use. In addition, the system allows for truly efficient control of energy consumption, which makes it possible to identify problem areas and find new opportunities to save resources.

Completed projects on integrated energy accounting

• Apartment metering of consumed energy resources: electricity, hot and cold water.
• Calculation of balances of energy consumption.
• Issuance of invoices for payment in automatic mode.

Our offer

The company "ENERGOAUDITKONTROL" offers services for the development and implementation of an effective automated system for integrated accounting of energy resources at your enterprise. We have extensive experience in the integration of such systems, from the design stage to the commissioning of the facility and the commissioning of the system. To build systems, advanced developments and the best equipment are used. This allows us to guarantee the maximum efficiency of accounting systems at a relatively low cost of their implementation.

In addition, our company completed the development and received a certificate of approval of the type of measuring instrument for the Automated Metering and Metering System for Electricity and Energy Resources "EC EAC" (ASKUER EC EAC), registration No. 60241-15, valid until 27.03.2020.

This allows you to significantly reduce the time and money spent on creating legitimate systems for commercial metering of energy resources for industrial enterprises and housing and communal services.
